Picture Of Magnetometer

Helium Vector Magnetometer (HVM) of the Pioneer 10 and Pioneer 11 spacecraft

The magnetometer measures magnetic fields in space and in the vicinity of Jupiter. The electronics of the magnetometer (left) are mounted in the spacecraft.
